. ELECTRICAL SPECIFICATIONS @25℃ 1. OCL: 350 μH min @100KHz 100mV 8mA DC Bias
2. Instertion Loss：-1.0dB max @ 1~100 MHz -1.2dB max @ 100~125 MHz
3. Return Loss: -18 dB Min @ 1~30 MHz.load 100Ω -14 dB Min @ 30~60 MHz.load 100Ω -12 dB Min @ 60~80 MHz.load 100Ω -10 dB Min @ 80~100 MHz.load 100Ω
4. Common Mode Rejection: -30 dB Min @ 1-100 MHz
5. Cross Talk: -30 dB Min @ 1-100 MHz
6. Isolation Hipot: 1500VAC 60s or 2250VDC 60s
7. Operating temperature : -40℃ to +85℃
8. Storage temperature : -40℃ to +85℃ 9.
RoHS complian
